· Smart charger with multi-protection functions
· Suitable for 24V lithium batteries
· Charging indicators
· Wide operating temperature range
· Build-in Reverse polarity protection
INQUIRY
Share it：
▎ Technical Parameters
Model
YL-CFY29
Name
Lithium battery charger / Power supply
Main parameters
Max. output power
423W
Input voltage
220VAC
Output voltage
29.4V+-0.2VDC
Output current
13A+-1.3A
Storage temperature
-40~75℃
Working temperature
-29~45.5℃
Dimension
L*W*H=233×108×64mm
AC Terminal
Customized
DC Terminal
Cable length
Input parameters
Rated input voltage
220Vac
Input voltage range
100 ~ 240Vac
AC input voltage frequency
50～60 Hz
Output characteristic
CC(constant current)
≤29.4Vdc, 13A
CV(constant voltage)
29.4Vdc, 13A↓
Power efficiency
≥94%
Protection functions
Over voltage protection
Software over voltage protection: The charger software limits the maximum output voltage to a level suitable for the connected battery system.
Over temperature protection
Current limiting protection
Short circuit protection:
Short circuit protection should be automatically recovery after remove the condition.
Reverse polarity protection:
When output wires are reversely connected to the battery the charger will not operate and will work normally when DC wires are correctly connected.
Charging indicator
Charging
LED: Red
Fully charged
LED: Green
▎ Advantages
· Smart charging with multi-protection functions
· Suitable for
