YiLiNK high-voltage battery system integrates premium high-cycle lithium iron phosphate cells and battery managementsystem with multiple levels of protection and monitoring.

The modular design and multiple levels of control allow you to meet a wide variety of backup needs for residential sitescommercial sites,industrial areas and communities.

The reliable battery cells and energy management system can soive the power demand of each scenario and also bring excellent retumn on investment for the owner.


Application:
Utility, Industrial & Commercial Projects
Certification:
Utility C&I Batteries AC+DC All in One Lithium Battery YILINK

Share it:

  • Specification
  • Features
  • Download
  • Video
System ModelYL-HV100kW/215kWh

System parameters

Nominal Power100kW
Nominal Energy215k
Voltage Range Dc600~864V
Output Voltage AC240/400Vac
Composition1P240S
Nominal Voltage DC768V
Cycle Efficiency≥93%
Cycle Life≥6000 Times
DimensionD1460*W1400*H2280mm
Ip RatingIP54
Weight 2500kg
Operating Temperature Range-20~50℃
Max, Operating Altitude≤3000m
Battery Temperature Control MethodLiquid Cooling
Firefighting MethodsFire Protection Inside the Cabinet
Communication NetworkEthernete
Communication ProtocolSupports lEC104, Modbus-RTU, DL/T645, etc
Parallel Capability5*Clusters(500kw/1MWh)
Battery Clusteter
Composition
1P240S
Nominal Capacity280Ah
Nominal Voltage768V
Nominal Energy215kWh
Weight1500kg
IP RatingIP65
Optimum Operating Temperature10~35℃

Cycle Efficiency@0.5c Cycle Life@0.50


System parameters
Max. DC Power 162kW
Max, input Current171A
DC Operating Voltage Range615~900V(3P3L)/650~950V(3P4L)
Nominal AC Power105kW
Max. AC Current167A
DimensionD484*W667*H271.5mm
Weight50kg
IP RatingIP20
MPPT Parameters
Nominal Power50kW
Single Channel Max. Current135A
Output Voltage RangeDC650~DC900V
Input Voltage RangeDC270~DC700V
Parallel Quantity2
Stable Voltage Accuracy<1%
Output Ripple<0.5%
Overload Capacity105% load, long-term operation
Storage Temperature-40~70 ℃ (without battery)
Working Temperature-20~55 (derating above 45 ℃)
Relative Humidity0% RH~95% RH, non condensing
Working Altitude≤2000m; 2000m~4000m Derated Use
Communication MethodsCAN/RS485
lsolation MethodNon isolated type
Maximum Efficiency98.20%
IP LevelIP20
Cooling MethodAir cooling, intelligent fan speed regulation
DimensionsD608.5*W530*H132mm
Weight30kg


■   Voltage from 192V to 1500Vdc with various capacities

■   Multi-level protections and monitoring

■   Smart monitoring and communication with Inverter, PCS and EMS

■   Various installation supports: wall mounting, rack mounting and container installations

■   Easy and flexible installation

■   Highly reliable lithium battery cells and BMS
