Yilink Solar System，Lithium Battery

High Voltage Battery 192-240V LifePO4Lithium Battery YlLlNK iPower

Return

High Voltage Battery 192-240V LifePO4Lithium Battery YlLlNK iPower

iPower is specially tailored for energy storage system, it offers a greater efficiency, higher reliability, intelligent battery management system, intelligent battery monitoring system, long lifespan to your solar system.

iPower LifePO4 batteries are ideal for off-grid and hybriId applications, offering a solution that's built for the long run and has the ability to be deployed and used in a variety of scenarios, for instance, residential, commercial, farm, factory, data room, holiday hotel, etc.

Application：

Certification：

INQUIRY

Share it：

Specification
Features
Download
Video

Model	YL-HV192100-50	YL-HV256100-50
Battery Type	LiFePO4
Nominal Voltage(V)	192	256
Nominal Capacity(Ah)	100	100
Nominal Energy(kWh)	19.2	25.6
Max. Output Power(kW)	9.6	12.8
Recommended Charge Current(A)	20	20
Max. Continuous Charge Current(A)	50	50
Max. Continuous Discharge Current(A)	50	50
Net Weight(kg)	200	260
Dimension(mm)WDH	580880420	5801040420
Installation Way	Indoor Floor Installatio
IP Rating	IP31
Battery Level	Brand New Premium Grade A Battery Cells
BMS Leve	High Precision Intelligent BMS
Alarm and Protection	Multiple Protections from Battery Cells to Battery Pack
Operating Voltag(V)	5162.00~219.00	216.00~292.00
Operating Temperature Charging	0~55°C
Operating Temperature Discharging	-20~60°C
Months Self Discharge	≤2%，@25℃
Efficiency Of Charge &Discharge	≥99.5%，@0.2C
Communication	Support up to 7PCS in Parallel
Cycle Life	More than 6,000 Times*
Communication	CAN/RS485/Dry Contact
Communication	Growatt, Deye, Sol-Ark, SunSynk, Goodwe, Sofar, etc
Parallel Capability	Support up to 7PCS in Parallel
Monitoring & Commissioning	PC Terminal or WiFi Module Remote Monitoring (Optional)
Warranty	5 to 10 Years
Certifications & Safety Standards	CE, IEC62619, IEC/EN61000-3, IEC/EN61000-6, ROHS, UL1973, UN38.3, MSDS

*: @0.2C, 80% DoD, 25℃

■ Parallel capability up to 7 units, meeting different site energy requirements

■ Excellent inverter communication compatibility:

■ Deye, Growatt, Sol-Ark, SunSynk, Victron, Voltronic, Goodwe, Luxpower, Sofar, SMA, Schneider, Solis, TBB, INVT, etc

■ PC Monitoring and optional WiFi remote monitoring & commissioning

■ Wall-mounted, floor-standing, and rack-mounted installations supported

■ International CLASS 9 dangerous goods packing certifcations

■ High energy density with light-weight

■ Full set of matched accessories supported

High Voltage Battery 192-240V LifePO4Lithium Battery YlLlNK iPower

Specification：High Voltage Battery 192-240V LifePO4Lithium Battery YlLlNK iPower.pdf
